Feature
· Advanced thick film technology
· Non-Nichrome Resistive Element
· Non-inductance working up to 18GHz
· Base Material is 99.7 % Alumina
· Return loss (VSWR) is lower than 1.2
· Thick Film single wrap chip termination plated with Gold over Nickel
· Terminals are wire bondable
· Compliant to RoHS directive 2011/65/EU
· Compliant to REACH (EC No. 1907/2006)) (last updated: 27/06/2018)
